- Standard: Comply with lEC92-3-84 and GB3126-82 “Non metallic Cable Ties for Ships” standard.
- Operating environment temperature:-25’C -60’C, High tensile strength.
- Material: Nylon 66, with good insulation performance, flame retardancy, and convenient operation.
| Item No. 产品规格 | Length mm(inch) 长度 | Width (mm) 宽度 | Bundle Diameter (mm) 捆扎范围 | Tensile Strength 承受力 | |
|---|---|---|---|---|---|
| LBS | KGS | ||||
| GS-3*100T | 100 (4) | 3.0 | 25 | 18 | 8 |
| GS-4*150T | 150 (6) | 4.0 | 35 | 45 | 20 |
| GS-4*200T | 200 (8) | 4.0 | 50 | 45 | 20 |
| GS-4*280T | 280 (11) | 4.0 | 70 | 45 | 20 |
| GS-4*370T | 370 (14.5) | 4.0 | 102 | 45 | 20 |
| GS-5*250T | 250 (10) | 5.0 | 65 | 50 | 22 |
| GS-5*300T | 300 (12) | 5.0 | 80 | 50 | 22 |
| GS-5*350T | 350 (13.75) | 5.0 | 90 | 50 | 22 |
| GS-5*430T | 430 (17) | 5.0 | 115 | 50 | 22 |
| GS-8*145T | 145(5.75) | 8.0 | 32 | 120 | 55 |
| GS-8*175T | 175 (7) | 8.0 | 42 | 120 | 55 |
| GS-8*200T | 200 (8) | 8.0 | 50 | 120 | 55 |
| GS-8*240T | 240 (9.5) | 8.0 | 56 | 120 | 55 |
| GS-8*300T | 300 (12) | 8.0 | 80 | 120 | 55 |
| GS-8*400T | 400 (15.75) | 8.0 | 100 | 120 | 55 |
| GS-10*300T | 300 (12) | 10.0 | 80 | 135 | 60 |
| GS-10*350T | 350 (14) | 10.0 | 90 | 135 | 60 |
| GS-10*400T | 400 (15.75) | 10.0 | 105 | 135 | 60 |
| GS-10*450T | 450 (17.75) | 10.0 | 115 | 135 | 60 |
| GS-10*500T | 500 (19.68) | 10.0 | 150 | 135 | 60 |
| GS-10*600T | 600 (23.625) | 10.0 | 170 | 135 | 60 |
